Alright guys and gals it's finally time to get started! I stopped at a local metal fav shop and grabbed some light gauge aluminum to make a thin prototype that is easily workable:



First off I cut off what was left of the lower bumper cover:

Before


After


The rest of the time spent tonight was relocating the transmission cooler lines and a lot of staring and scratching my head on deciding how and where I want to mount...

I've got very limited free time so this may be a very slow and boring thread! I'll try and make it as quick as I can and not drag it out forever!
