Re: Addco Rear Sway w/Greasable Bushings

Quote:
Originally Posted by MacDee View Post
Got it all done...

Bilstiens Shocks, Eibachs Lowering Springs, Front SRT Swaybar and the Rear Addco Swaybar with the Energy Greasable Bushing.

The Jeep feels great, worth every penny.

The question is... Is an Ailgnment of all 4 corners required?

It doesn't feel or looks like is needed.

yes bro....get an alignment! They dont look out until you see your tirea wearing unevenly

---------- Post added at 07:47 PM ---------- Previous post was at 07:46 PM ----------

Quote:
Originally Posted by MacDee View Post
Got it all done...

Bilstiens Shocks, Eibachs Lowering Springs, Front SRT Swaybar and the Rear Addco Swaybar with the Energy Greasable Bushing.

The Jeep feels great, worth every penny.

The question is... Is an Ailgnment of all 4 corners required?

It doesn't feel or looks like is needed.

post some pics too!!!!!
__________________

__________________
SCOTT
The HARDER you work...the LUCKIER you are!
2014 REDLINE red Jeep SRT "BLOODIED Edition" 1 of 1
Previous JEEP rides-
2013 Jeep Grand Cherokee SRT-deep cherry
2013 JKU 10th anniversary-white
2006 Jeep Grand Cherokee Laredo-inferno red



Twitter-The_Jeep_Guy
Instagram-thejeep_guy

Reply With Quote
  #26
Old 07-12-2009, 07:50 PM
MacDee's Avatar
Member

Join Date: Jun 2009
Location: Bronx, New York
Posts: 26
Thanks: 0
Thanked 0 Times in 0 Posts
Rep Power: 1888
MacDee is on a distinguished road
Re: Addco Rear Sway w/Greasable Bushings

Quote:
Originally Posted by Scottina06 View Post
yes bro....get an alignment! They dont look out until you see your tirea wearing unevenly, post some pics too!!!!!
Thanks for the advice... also here's some pictures.













__________________

__________________
Mac

-------------------------------------------------
2008 GC Overland 5.7 HEMI w/ some Mods...

Magnaflow Catback Exhaust / Volant CAI / DiabloSport Predator /
Bilstiens with Eibach Springs / Addco Rear, SRT Front Swybars
Reply With Quote
  #27
Old 07-21-2009, 06:46 PM
RyanB's Avatar
Member

Join Date: Jun 2009
Posts: 61
Thanks: 0
Thanked 0 Times in 0 Posts
Rep Power: 1907
RyanB is on a distinguished road
Re: Addco Rear Sway w/Greasable Bushings

Hey Rob (and anyone else that can answer),

Do you know what the part no. is for the Energy greasable bushings? Today I broke one and the Addco rear bar was rattling like a mutha. The guys at Mavis actually made something for me and get this they put in 2 hours of work, stayed over an hour later for me after they closed and didn't charge me a thing. I thanked them with a smile and a nice tip! :-)

What they did works but I still think I may want to pick up a couple of these bushings.

As per the link below, if the rear sway is 22mm thick then I'll need the following: [7/8" / 22mm] ----> Part no. 9.5158

http://www.energysuspension.com/pages/swaybbct.html

Here's a photo. the part that broke is the metal piece.






Quote:
Originally Posted by robpp View Post
A few weeks ago did the rear Bilsteins. Today the rear Addco with greasable bushings from energy suspension.
The stock rear sway is 16 mm, the ADDCO is 22mm. Also, with the Poly Bushings, grease is needed to avoid squeeks.
To start i bought some overpriced Energy Suspension grease. But a Marine type grease is recommended. Maybe a few squirts once a year....
I onkly had to remove the wheels to get the old out and new one in. Took about 90 minutes by myself on the garage floor.
You need a 8MM to hold the end and a 18MM for the nut that's on the end. Then the bushings mounts are 5/8 bolts.

Some pics :
THe bar end:


the greasable bushing:




tooke a quick spin make sure no squeaks, notice 2 Po-Po following me so i had to behave. some testing later this week.

next up front bilsteins, need painting first. satin black like my rear ones.
__________________
-RYAN- 05 Black Limited WK. HEMI. Bilsteins. ADDCO sway. MOPAR CAI. Slush Mats. XENONDEPOT Philips lows/fogs. LED Tails. 18" Saharas Wheels w/255s. 20" Zinik Z12 Mazotti w/ Kumho Ecsta STX 275/45/20 (SUMMER WHEELS). 18" turbo tube muffler. Black Laredo Grill. 20% tints. Sub/Amp Nav. More?:D
Reply With Quote
  #28
Old 07-21-2009, 07:03 PM
Scottina06's Avatar
JeepGarage Founder
My Jeep: 2014 6.4L SRT8 WK2

Join Date: May 2009
Location: Berea, Kentucky
Posts: 48,739
Thanks: 816
Thanked 799 Times in 619 Posts
Rep Power: 7717304
Scottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond repute
Garage
Re: Addco Rear Sway w/Greasable Bushings

Quote:
Originally Posted by MacDee View Post
Thanks for the advice... also here's some pictures.













Looks awesome Mac! Congrats!

---------- Post added at 08:03 PM ---------- Previous post was at 08:01 PM ----------

Quote:
Originally Posted by RyanB View Post
Hey Rob (and anyone else that can answer),

Do you know what the part no. is for the Energy greasable bushings? Today I broke one and the Addco rear bar was rattling like a mutha. The guys at Mavis actually made something for me and get this they put in 2 hours of work, stayed over an hour later for me after they closed and didn't charge me a thing. I thanked them with a smile and a nice tip! :-)

What they did works but I still think I may want to pick up a couple of these bushings.

As per the link below, if the rear sway is 22mm thick then I'll need the following: [7/8" / 22mm] ----> Part no. 9.5158

http://www.energysuspension.com/pages/swaybbct.html

Here's a photo. the part that broke is the metal piece.

do you still have your stock pieces? If so..... use the old one
__________________
SCOTT
The HARDER you work...the LUCKIER you are!
2014 REDLINE red Jeep SRT "BLOODIED Edition" 1 of 1
Previous JEEP rides-
2013 Jeep Grand Cherokee SRT-deep cherry
2013 JKU 10th anniversary-white
2006 Jeep Grand Cherokee Laredo-inferno red



Twitter-The_Jeep_Guy
Instagram-thejeep_guy

Reply With Quote
  #29
Old 07-21-2009, 08:22 PM
RyanB's Avatar
Member

Join Date: Jun 2009
Posts: 61
Thanks: 0
Thanked 0 Times in 0 Posts
Rep Power: 1907
RyanB is on a distinguished road
Re: Addco Rear Sway w/Greasable Bushings

Hi Scott, yes I do. Oh a sec... are you suggesting that the stock metal bracket will work? If so, I'll have to find it in the garage.... hmmm.. Thanks Scott.
__________________
-RYAN- 05 Black Limited WK. HEMI. Bilsteins. ADDCO sway. MOPAR CAI. Slush Mats. XENONDEPOT Philips lows/fogs. LED Tails. 18" Saharas Wheels w/255s. 20" Zinik Z12 Mazotti w/ Kumho Ecsta STX 275/45/20 (SUMMER WHEELS). 18" turbo tube muffler. Black Laredo Grill. 20% tints. Sub/Amp Nav. More?:D
Reply With Quote
  #30
Old 07-21-2009, 08:53 PM
Long Live the Graphite Ghost


Join Date: May 2009
Posts: 13,395
Thanks: 54
Thanked 131 Times in 113 Posts
Rep Power: 542541
robpp has disabled reputation
Re: Addco Rear Sway w/Greasable Bushings

you have the right Energy Suspension part number there.

and try what scott says.....
__________________
Reply With Quote
  #31
Old 07-21-2009, 09:09 PM
RyanB's Avatar
Member

Join Date: Jun 2009
Posts: 61
Thanks: 0
Thanked 0 Times in 0 Posts
Rep Power: 1907
RyanB is on a distinguished road
Re: Addco Rear Sway w/Greasable Bushings

Thank you gentlemen! I'll update you ASAP. Hopefully I can find the old bushings.
__________________
-RYAN- 05 Black Limited WK. HEMI. Bilsteins. ADDCO sway. MOPAR CAI. Slush Mats. XENONDEPOT Philips lows/fogs. LED Tails. 18" Saharas Wheels w/255s. 20" Zinik Z12 Mazotti w/ Kumho Ecsta STX 275/45/20 (SUMMER WHEELS). 18" turbo tube muffler. Black Laredo Grill. 20% tints. Sub/Amp Nav. More?:D
Reply With Quote
  #32
Old 07-21-2009, 10:19 PM
Scottina06's Avatar
JeepGarage Founder
My Jeep: 2014 6.4L SRT8 WK2

Join Date: May 2009
Location: Berea, Kentucky
Posts: 48,739
Thanks: 816
Thanked 799 Times in 619 Posts
Rep Power: 7717304
Scottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond repute
Garage
Re: Addco Rear Sway w/Greasable Bushings

yes....most people i have known that installed the addco sways used the stock bushing metal thingys....LOL The addco ones are crap...but i guess you know that....
__________________
SCOTT
The HARDER you work...the LUCKIER you are!
2014 REDLINE red Jeep SRT "BLOODIED Edition" 1 of 1
Previous JEEP rides-
2013 Jeep Grand Cherokee SRT-deep cherry
2013 JKU 10th anniversary-white
2006 Jeep Grand Cherokee Laredo-inferno red



Twitter-The_Jeep_Guy
Instagram-thejeep_guy

Reply With Quote
  #33
Old 07-22-2009, 09:49 PM
RyanB's Avatar
Member

Join Date: Jun 2009
Posts: 61
Thanks: 0
Thanked 0 Times in 0 Posts
Rep Power: 1907
RyanB is on a distinguished road
Re: Addco Rear Sway w/Greasable Bushings

Scott, you're the man, The stock ones are WAAAAAY better. I found them today. These will be installed as soon as I get a chance to go back to Mavis or when its breaks again! Mucho Gracias. You too Rob.
__________________
-RYAN- 05 Black Limited WK. HEMI. Bilsteins. ADDCO sway. MOPAR CAI. Slush Mats. XENONDEPOT Philips lows/fogs. LED Tails. 18" Saharas Wheels w/255s. 20" Zinik Z12 Mazotti w/ Kumho Ecsta STX 275/45/20 (SUMMER WHEELS). 18" turbo tube muffler. Black Laredo Grill. 20% tints. Sub/Amp Nav. More?:D
Reply With Quote
  #34
Old 07-22-2009, 11:05 PM
Scottina06's Avatar
JeepGarage Founder
My Jeep: 2014 6.4L SRT8 WK2

Join Date: May 2009
Location: Berea, Kentucky
Posts: 48,739
Thanks: 816
Thanked 799 Times in 619 Posts
Rep Power: 7717304
Scottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond repute
Garage
Re: Addco Rear Sway w/Greasable Bushings

sorry bro....I wish i had known before you installed them. I had the addco front sway for a day.....the first batch was pretty bad off and we used the stock brackets as well.
__________________

__________________
SCOTT
The HARDER you work...the LUCKIER you are!
2014 REDLINE red Jeep SRT "BLOODIED Edition" 1 of 1
Previous JEEP rides-
2013 Jeep Grand Cherokee SRT-deep cherry
2013 JKU 10th anniversary-white
2006 Jeep Grand Cherokee Laredo-inferno red



Twitter-The_Jeep_Guy
Instagram-thejeep_guy

Reply With Quote
