Thumbs up JEEPGARAGE Exclusive--2014 HID LED headlight...up close and personal! Taken apart!




Jeep performance lighting.....66MM projector

headlight washer from front

headlight washer from bottom


headlight washer spray nozzle



wash connection

NEW hid cover-twists off and seals really well

NEW D3S bulbs

bulb removed

leveling system controls?

headlight control module?

HID ballast



There is ONLY 1 bulb to replace...the new D3S hid bulb. Everything else is contained internally. I assume the black Mopar box controls the headlamps. There is a connection for the headlight washer and I assume that is from the washer tank. Not sure if water pressure pushes the sprayer out....or if theres a motor to push it out somewhere else? It is hard to push out and is spring activated with a very tight spring!
Very interesting to say the least....
