New engine and "intake system"

I've enjoyed the techco twin screw for a while. Solid 10 second jeep in full trim, great instant acceleration, but I've been accumulating some parts for a while, about to get to work making them work now.


Casting sig for...


a alum new block, still in the wrapper

block upskirt, nice mains...


Carillo rods


that will connect to Ross pistons


one ring to squeeze them all...


new jeep fuel hat from Fixer Dave Sawin - triple 340s, billet basket set up for a-n fittings -10 out and -6 in.


high tech fuel squirters from ID


Intermission - Tech tip - If anyone was curious about the rocker bones/head straps part numbers - 6.1 vs apache, they really are a little different...

Speaking of heads, Ronnie Crawford is completing the port job on some Apache heads now, with Ferrera 8mm whizbang valves to be backcut and angled, PAC 1555 springs, Victory 10 deg Ti retainers and single groove keepers and guides of suitable spec. I was lucky enough to get him to hand finish a set for me while he was doing Buckwheat's. Sorry no pics yet., well, maybe one or two...

intake port


exhaust port


chamber clean up


Eddie Gregory and Billy Drakeford at SHR will be putting my block together - machining it in house this week, block is already next door getting fitted for machining.
The Techco twin screw should really like a new 4.18x bore block and ported apache heads.
Will also get an updated SHR War Viking transmission while the block is being switched.





Then again, maybe I could change the lungs, while the engine's out and all...

Cool gadget, but what's it for.....


To control all of this...

Twin Turbo Creations 67/66 ball bearing billet ball buster balls out Jeep turbo kit.
Coated image...

This kit is performing very well on some other builds, well designed, well sized, well balanced, best clamps. Chris is a great vendor.


Gonna need a new intake manifold...


So Ronnie Crawford also ported and machined a beer keg intake to accept a 90mm...

and smoothed the runners and bosses so the air will flow....


Can't have cold turbos..., Chris, the coating done yet?


and I guess I'll need a new badge...

Probably need a Techco for sale thread, too.

So there's the grocery list. Been quietly accumulating for months, which has in itself been lots of fun, especially with all the new turbo builds popping up out there. Have just about everything. Once heads are completed and delivered, a turbo cam of suitable spec will be designed by Eddie and Billy in collaboration with Cammotion, who just happens to have some of Crawford's better turbo cams on file to start with. Not going in the shop just yet, first will be heading up the highway a bit to Jason Wood of Wizard Racing for some safety. Maybe its all done in time to make FL in January 2013.
__________________

__________________
:confused:

[SIGPIC][/SIGPIC]
Reply With Quote
  #2
Old 09-11-2012, 09:07 AM
Scottina06's Avatar
JeepGarage Founder
My Jeep: 2014 6.4L SRT8 WK2

Join Date: May 2009
Location: Berea, Kentucky
Posts: 49,421
Thanks: 877
Thanked 1,054 Times in 728 Posts
Rep Power: 7718345
Scottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond repute
Garage
Re: New engine and "intake system"

WOW....epic thread George! Impressive
__________________

__________________
SCOTT
The HARDER you work...the LUCKIER you are!
2014 REDLINE red Jeep SRT "BLOODIED\BlackOps CFR Edition" 1 of 1
2013 JKU Wrangler 10A-stormtrooper'ed, JW Speaker and more!
Previous JEEP rides-
2013 Jeep Grand Cherokee SRT-deep cherry
2006 Jeep Grand Cherokee Laredo-inferno red



Twitter-The_Jeep_Guy
Instagram-thejeep_guy

Reply With Quote
  #3
Old 09-11-2012, 09:46 AM
stashgto's Avatar
Member
My Jeep: 2008 3.7L WK

Join Date: May 2012
Location: Staten Island N.Y.
Posts: 720
Thanks: 0
Thanked 18 Times in 18 Posts
Rep Power: 110027
stashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond repute
Re: New engine and "intake system"

You better add a ball strap to your list of safety gear!
__________________
Reply With Quote
  #4
Old 09-11-2012, 01:03 PM
jrjeep's Avatar
Member
My Jeep: 2005 3.7L WK

Join Date: Feb 2012
Location: SoCal
Posts: 442
Thanks: 0
Thanked 10 Times in 10 Posts
Rep Power: 1426
jrjeep is on a distinguished road
Garage
Re: New engine and "intake system"

wow...
__________________
Build thread..
http://www.jeepgarage.org/f14/jrjeep-black-05-wk-build-thread-44273.html

[SIGPIC][/SIGPIC]
Reply With Quote
  #5
Old 09-11-2012, 09:24 PM
viking757's Avatar
Member
My Jeep: 2008 6.1L SRT8

Join Date: May 2010
Location: NOVA
Posts: 792
Thanks: 0
Thanked 23 Times in 23 Posts
Rep Power: 19961
viking757 has a reputation beyond reputeviking757 has a reputation beyond reputeviking757 has a reputation beyond reputeviking757 has a reputation beyond reputeviking757 has a reputation beyond reputeviking757 has a reputation beyond reputeviking757 has a reputation beyond reputeviking757 has a reputation beyond reputeviking757 has a reputation beyond reputeviking757 has a reputation beyond reputeviking757 has a reputation beyond repute
Garage
Re: New engine and "intake system"

That's going to be nuts!
__________________
Reply With Quote
  #6
Old 09-11-2012, 09:35 PM
stashgto's Avatar
Member
My Jeep: 2008 3.7L WK

Join Date: May 2012
Location: Staten Island N.Y.
Posts: 720
Thanks: 0
Thanked 18 Times in 18 Posts
Rep Power: 110027
stashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond reputestashgto has a reputation beyond repute
Re: New engine and "intake system"

Thanks
__________________
Reply With Quote
  #7
Old 09-12-2012, 09:36 AM
Member
My Jeep: 2007 6.1L SRT8

Join Date: Aug 2012
Location: Houston, Tx
Posts: 44
Thanks: 0
Thanked 0 Times in 0 Posts
Rep Power: 845
La-Bestia is on a distinguished road
Re: New engine and "intake system"

dayyyyummmmm!!!!!!
__________________
07 SRT8, LMI cold air intake, Corsa w/5" tips, Eibach springs, Billet oil catch can, Billet filler caps, custom engraved brushed aluminum hood liner and fuse box covers, Ported and Polished Intake Manifold, Thermolator Intake Gaskets, Chrome Strut Tower Bar, OBX long tube headers w/cat delete, R1 drilled&slotted rotors, Zeckhausen racing brake pads, 22" factory reps, Diablo CMR tune, 180 thermostat, taillight solutions kit, matched body color fan shroud.
Reply With Quote
  #8
Old 09-12-2012, 03:56 PM
Long Live the Graphite Ghost


Join Date: May 2009
Posts: 13,418
Thanks: 55
Thanked 133 Times in 115 Posts
Rep Power: 542674
robpp has disabled reputation
Re: New engine and "intake system"

all i have to say is WOWOWOWOW


cant wait to see some more details george.......you been a busy shoppER!
__________________
Reply With Quote
  #9
Old 09-12-2012, 03:59 PM
*sox*'s Avatar
Italien MOPAR Guy :-)


Join Date: Oct 2011
Location: Basel / Switzerland
Posts: 1,891
Thanks: 89
Thanked 76 Times in 63 Posts
Rep Power: 571005
*sox* has a reputation beyond repute*sox* has a reputation beyond repute*sox* has a reputation beyond repute*sox* has a reputation beyond repute*sox* has a reputation beyond repute*sox* has a reputation beyond repute*sox* has a reputation beyond repute*sox* has a reputation beyond repute*sox* has a reputation beyond repute*sox* has a reputation beyond repute*sox* has a reputation beyond repute
Send a message via MSN to *sox* Send a message via Skype™ to *sox*
Re: New engine and "intake system"

Wow!

Cant wait to see more.
__________________
All Uconnect Software

www.mydrive.ch

username: mygig@soxag
Password: gasolio

Reply With Quote
  #10
Old 09-12-2012, 07:13 PM
Member
My Jeep: 2011 5.7L WK2

Join Date: Aug 2011
Location: Canada
Posts: 131
Thanks: 0
Thanked 1 Time in 1 Post
Rep Power: 1305
ernestd is on a distinguished road
Re: New engine and "intake system"

Great job Buddy.
Looking forward to seeing the finished product.
Enjoy the build!
__________________
Reply With Quote
  #11
Old 10-06-2012, 09:45 AM
muellge's Avatar
Member
My Jeep: 2007 7.0L SRT8

Join Date: Jun 2010
Location: NOLA
Posts: 198
Thanks: 2
Thanked 4 Times in 3 Posts
Rep Power: 1787
muellge is on a distinguished road
Re: New engine and "intake system"

The bore and hone is done. So is the balance on the crank. Jeep is getting some interior pipes this week. Still waiting for heads to get flowed so we can make a cam....
__________________
:confused:

[SIGPIC][/SIGPIC]
Reply With Quote
  #12
Old 10-06-2012, 06:35 PM
SvenskaJeepGuy's Avatar
Let's Roll
My Jeep: 2005 4.7L WK

Join Date: Dec 2009
Location: Scranton PA
Posts: 13,091
Thanks: 140
Thanked 163 Times in 153 Posts
Rep Power: 1255421
SvenskaJeepGuy has a reputation beyond reputeSvenskaJeepGuy has a reputation beyond reputeSvenskaJeepGuy has a reputation beyond reputeSvenskaJeepGuy has a reputation beyond reputeSvenskaJeepGuy has a reputation beyond reputeSvenskaJeepGuy has a reputation beyond reputeSvenskaJeepGuy has a reputation beyond reputeSvenskaJeepGuy has a reputation beyond reputeSvenskaJeepGuy has a reputation beyond reputeSvenskaJeepGuy has a reputation beyond reputeSvenskaJeepGuy has a reputation beyond repute
Garage
Re: New engine and "intake system"

wow!
